Cutera Xeo Navigation System

Cutera Xeo Navigation System

The Cutera Xeo Navigation can provide the most versatile laser and light technologies on the market today. Whether you are interested in skin tightening, skin rejuvenation, hair removal, vascular therapies – or all the above – the Xeo can accommodate your specific needs through our upgradeable platform.

The Cutera Xeo Platform supports the following Technologies

Nd Yag Handpiece – with 3 applications as listed below:

• The CoolGlide laser was the first laser cleared for permanent hair reduction / hair removal in all skin types and is endorsed by physicians worldwide.
• Treat all skin types (I-VI) including tanned skin in the summer.
• Patented PowerFlex technology provides fast treatments and high efficacy; allows independent control of fluence, pulse duration and repetition rates to tailor your treatment parameters.
• Copper cooling provides the most efficient method of cooling for optimal skin protection and comfort.
• Large spot size (10 mm) for maximum speed and optimal penetration at all follicle depths.

• The first clinically effective long-pulsed Nd:YAG laser for both facial and lower extremity vascular lesions.
• The Cutera Xeo safely and effectively treats discrete vessels, high pressure vessels and deep veins.
• Patented PowerFlex technology provides fast treatments and high efficacy; allows independent control of fluence, pulse duration and repetition rates to tailor your treatment parameters.
• Contact copper cooling provides the most efficient method of cooling for optimal skin protection and comfort.
• The clearview handpiece feature prevents vessel closure due to contact pressure.
• Easy on-the-fly spot size adjustment (3, 5, 7 mm) facilitates optimal selection for safety and results.

• Laser Genesis is a staple of skin care for every doctors practice. It is a multi-purpose, all season, all skin type solution for overall skin health.
• Cuteras 1064 nm wavelength, combined with our patented microsecond technology, protects the epidermis, targets microvasculature and stimulates collagen production.
• Improves wrinkles by gently heating the dermis; corrects diffuse redness, rosacea; smoothes skin texture, shrinks pore size.
• Peer reviewed journal shows evidence of erythema reduction and new collagen formation in the papillary dermis (Archives of Dermatology, Nov 2004).
• No downtime, minimal discomfort, no disposables.

Titan Handpiece – Titan V Handpiece – Small Areas; Titan XL Handpiece – Large Areas

Titan is the most researched and peer-reviewed infra-red solution for deep dermal heating of all skin.

Titans light source generates energy from 1100 to 1800 nm for safe and effective volumetric heating of the dermis.

Titan candidates are often patients not yet ready for surgery.

When combined with other non-ablative procedures that improve conditions such as dyschromia, Titans toning effect enhances overall results.

LimeLight Handpiece-

LimeLight is the most versatile, programmable device for treating vascular and pigmented lesions.

Three distinct pre-set programs (520-1100 nm) provide excellent hemoglobin and melanin absorption for uniform treatments and ease of use.

Clinical versatility permits treatment of multiple indications, including both low and high contrast pigmentation.

Features such as the industry’s fastest treatment speed and adjustable temperature control provide clinical versatility.

Only company with real-time calibration; this ensures accurate and consistent power output during treatment for reproducible results and patient safety

ProWave Handpiece

ProWaves multiple wavelength technology switches modes from Alexandrite to Diode to near Nd:YAG for maximum results, safety and versatilityall in a single high speed device.  It is indicated for the use of facial Hair Removal for Skin Type: I – III – Face, and Skin Type: IV & III (with excessive tanning/bronzing).

ProWave (770-1100 nm), combines unrivaled treatment speed with optimal results and safety.

Maximum versatility is achieved multiple wavelength technology enabling treatment modes from Alexandrite to Diode to near Nd:YAG.

Clinical studies showed > 80% hair reduction six months post three treatments.

ProWave LX Handpiece

ProWave LX overcomes the limits of other IPL technology for hair removal. Lighter and finer hair removal is more easily possible with the better targeting capabilities. The ProWave LX provides a fast, comfortable hair removal treatment that can be used on small and large areas.

Pearl Handpiece

Pearl delivers superior results in fewer treatments with less patient downtime than with non-fractional ablative lasers.

Indicated for fine wrinkles, dyschromia, skin tone and texture

Full epidermal renewal is achieved with YSGGs 2790 nm wavelength.

Patients receive 1-2 treatments without weeping and oozing and recover in 3-4 days.

Pearl Fractional Handpiece

Pearl Fractionals deep ablation and controlled thermal zone delivers maximum single-treatment results with less patient discomfort, downtime and risk than CO2.

Indicated for moderate to severe photoaging.

The 2790 nm wavelength (YSGG) controls thermal damage to maximize ablation while maintaining thermal stimulation and coagulation.

Controlled thermal zone minimizes risk of PIH and other complications.

Single treatment results are possible because our large 300 micron spot size ablates enough tissue in one pass.

Wound healing causes increased fibroblast activity and long term collagen deposition.

Improvement is realized over six month period.

A recent comparative study to other fractional devices demonstrated that Pearl Fractional was a more comfortable patient experience; further, the treatment is possible with only topical anesthetics and/or local nerve blocks

AcuTip Handpiece

AcuTip delivers optimal results with targeted focal treatments of pigmented and vascular lesionswith no risk to surrounding skin.

Small tip allows agressive pinpoint treatments  without compromising safety.

Selective wavelengths (500-635 nm) with short pulse durations deliver a powerful focal treatment.

Ideal for treatment of both low and high contrast pigmented lesions.

As powerful as Q-switched lasers for epidermal pigmentation; low risk of associated PIH

LP560 Handpiece

The Cutera LP560 is a pulsed light handpiece that works with both the Solera Opus and the Xeo series of systems. Used most commonly in the removal of benign pigmented lesions (BPLs) and solar lentigines, the LP560 can be used for any treatments that require selective photothermolysis of target chromophores in soft tissue. Emitting visible pulsed light at 560-1200nm through a 10-30mm clear window, no aiming beam is necessary; however, it is important that the entire window maintain contact with a patients skin during treatment.

Candidates for LP560 Treatments

While the LP560 is one of the most effective tools in BPL removals, it is not recommended for use on patients with Fitzpatrick Skintype VI or those with significant exposure to sun or artificial light (tanning) within the previous four weeks. Instead, the handpiece is intended for patients with Fitzpatrick skintypes I-IV with cautionary use on skintypes IV and V. Correct fluence should be determined by the table below, but variations will exist (i.e. lower fluences for darker target areas and bony areas).

Cutera XEO Laser Hair Removal Machine

What is Cutera Xeo?

How does Cutera Xeo Work?

What Conditions can Cutera Xeo Treat?

• Age spots
• Brown spots
• Facial redness
• Fine lines
• Large pores
• Pigmented lesions
• Scars
• Spider veins
• Sun spots
• Unwanted hair
• Vascular lesions
• Wrinkles

What makes Cutera Xeo Laser Treatment so Effective?

• TruPulse Technology: Provides consistent, sustained energy to the target area for optimal results.
• Nd:YAG Technology: It’s FDA-approved for the treatment of a multitude of skin concerns.
• Epidermal Cooling: Provides continuous temperature regulation for improved patient comfort.
• Intense Pulsed Light (IPL): This menu can be used as an individual or combined treatment for various signs of skin aging.
• Energy Control: Allows practitioners to conduct real-time calibration.

Handpieces

1. Nd:YAG: Designed for treatment of unwanted hair and vascular lesions on different body areas.
2. LimeLight: It’s an ideal treatment for sun spots, benign pigmented lesions, and vascular lesions.
3. ProWave LX: Designed for removal of unwanted hair in small and large body areas.
4. AcuTip: Used for treatment of sun spots and small spider veins on the face, nose, cheeks, and chin.
5. Titan: Used for sustained deep dermal heating of the face, chin, neck, and abdomen.
6. Pearl Er:YSGG: Recommended for the treatment of sun pots, age spots, and wrinkles.
7. Pearl Fractional Er:YSGG: It addresses acne scarring, wrinkles, large pores, and irregular skin texture.
